ZKJ型真空机组

ZKJ真空箱机组是通过2X型真空泵、真空箱、电器箱、真空表、电磁放气阀五大类组成真空箱机组。真空泵在形成一定要求的真空或压力时，从而满足工艺过程要在真空状态下进行的要求。ZKJ真空箱机组可广泛适用于工艺品、化工、制药、冶金、电子、科研等行业。

+86 0577-67988669

立即咨询 PDF下载

ZKJ真空箱机组是通过2X型真空泵、真空箱、电器箱、真空表、电磁放气阀五大类组成真空箱机组。真空泵在形成一定要求的真空或压力时，从而满足工艺过程要在真空状态下进行的要求。ZKJ真空箱机组可广泛适用于工艺品、化工、制药、冶金、电子、科研等行业。
ZKJ vaeuum box unit is a vacuum box unit, whieh consists of 2X vacuum pump. vacuum box, electric appliance box, vacwum meter and electromugnetie dlnin valve. w hen ertain vacuum or pressure is obtained in the vacum pump, the requirement of processing the procedures in racuum is mel.

ZJK vacuum box unit is to be widely applied to many industries such as cralfts, chemical, pharmaceutieal, metallurgy, eleetronie, researeh and so on.

型号 Type	设备配置		极限真空(Pa)	功率(KW)
型号 Type	真空箱(方形)宽 x 高 x 深(mm)	配用真空泵	极限真空(Pa)	功率(KW)
ZKJ-400	400 x 400x400	2X-8/2X-15	6x10-2	1.1/1.5
ZKJ-450	450x450x 400	2X-15/2X-30	6x 10-2	2001-05-03
ZKJ-500	500x 500x450	2X-15/2X-30	6x 10-2	36953
ZKJ-600	600 x 600x 500	2X-30/2X-70	6x10-2	2003-05-05
ZKJ-700	700x 600x 600	2X-70/2X-100	6x 10-2	5.5/7.5
ZKJ-800	800x 700x 600	2X-70/2X-100	6x10-2	5.5/7.5
ZKJ-900	900x 800x 600	2X-70/X-100/X-150	6x10-2	5.5/7.5/15
ZKJ-1000	1000 x800x 800	2X-70/X-100/X-150	6x10-2	5.5/7.5/15
ZKJ-1000	1000x 1000x 800	2X-70/X-100/X-1 50	6x10-2	5.5/7.5/15
ZKJ-250	250x 500	2X-4A/2X-8A	6x10-2	0.55/1.1
ZKJ-400	400x650	2X-8A/2X-15A	6x10-2	1.1/1.5
ZKJ-500	500x800	2X-15A/2X-30	6x10-2	2001-05-03
ZKJ-600	600x850	2X-15A/2X-30	6x10-2	37014
ZKJ-700	700x 1000	2X-30/2X-70	6x10-2	2003-05-05
ZKJ-800	800x 1100	2X-70/X-100/X-150	6x10-2	5.5/7.5/15
